FUJITSU Workstation CELSIUS W550 Long Lifecycle
Do you require a minimum lifecycle of 36 months? Than the FUJITSU CELSIUS W550power Long Lifecycle desktop workstation is the ideal choice, especially for video editing, MCAD/electrical CAD or Architecture, Engineering and Construction applications. Enjoy best-in-class low noise emissions of only 18 dB(A) for a quiet and efficient working environment.
- Workstation CELSIUS W550 Long Lifecycle VER STYLE SHEET EM PDF
- Operating system Windows 10 Pro. Fujitsu recommends Windows 10 Pro.
- Windows 10 Home
- Windows 7 Professional (available through downgrade rights from Windows 10 Pro)
- Additional software (preinstalled) Workplace Protect (secure authentication solution)
- Adobe® Reader® (pdf reader)
- McAfee Multi Access Security (anti-virus and internet security software; 60 days trial version)
- Win7: Fujitsu Recovery (hard disk based recovery)
- Win8: Microsoft Push Button Recovery (hard disk based recovery)
- Microsoft Office (buy license to activate the pre-installed Microsoft Office)
- Mainboard D3417 (µATX)
- Chipset Intel® C236
- Processor Type, Second Level cache, Processor frequency Intel® Xeon® processor E3-1275v5, 8 MB, 3.60 GHz, up to 4.0 GHz
- Intel® Xeon® processor E3-1225v5, 8 MB, 3.30 GHz, up to 3.7 GHz
- Intel® Core™ i3-6100 processor, 3 MB, 3.70 GHz
- Processor quantity maximum 1
- Supported capacity RAM (max.) 64 GB, 4 Memory slot(s) DIMM (DDR4) ECC/non-ECC, Dual channel support, For dual channel performance, a minimum of 2 memory modules have to be ordered. Capacity per channel has to be the same.
- Serial ATA 6 x Serial ATA total
- thereof eSATA 2 (optional)
- Controller functions Serial ATA III (6 Gbit), NCQ, AHCI, RAID 0/1/5/10
- Drives (optional) MultiCard Reader 24in1 USB 2.0 3.5", USB 2.0
- DVD-ROM
- DVD Super Multi, SATA
- DVD Super Multi ultra slim (tray), SATA
- BD Triple Writer SATA ultra slim (tray), SATA
- Hard disk drive SSD SATA III, 1024 GB, 2.5-inch
- SSD SATA III, 960 GB High Endurance, 2.5-inch
- SSD SATA III, 512 GB, 2.5-inch, SED
- SSD SATA III, 512 GB, 2.5-inch
- SSD SATA III, 480 GB High Endurance, 2.5-inch
- SSD SATA III, 256 GB, 2.5-inch, SED
- SSD SATA III, 256 GB, 2.5-inch
- SSD SATA III, 240 GB High Endurance, 2.5-inch
- SSD SATA III, 128 GB, 2.5-inch
- SSD PCIe, 1024 GB M.2 NVMe Highend module
- SSD PCIe, 512 GB M.2 NVMe Highend module
- SSD PCIe, 256 GB M.2 NVMe Highend module
- SSD PCIe, 1x1024 GB M.2 NVMe Highend card
- SSD PCIe, 1x 512 GB M.2 NVMe Highend card
- SSD PCIe, 1x 256 GB M.2 NVMe Highend card
- HDD SATA III, 7,200 rpm, 1000 GB, 2.5-inch, enhanced availability
- HDD SATA III, 7,200 rpm, 500 GB, 3.5-inch
- HDD SATA III, 7,200 rpm, 500 GB, 2.5-inch, enhanced availability
- HDD SATA III, 7,200 rpm, 6,000 GB, 3.5-inch, business critical
- HDD SATA III, 7,200 rpm, 4,000 GB, 3.5-inch, business critical
- HDD SATA III, 7,200 rpm, 2,000 GB, 3.5-inch, business critical
- HDD SATA III, 7,200 rpm, 2,000 GB, 3.5-inch
- HDD SATA III, 7,200 rpm, 2,000 GB, 2.5-inch, business critical
- HDD SATA III, 7,200 rpm, 1,000 GB, 3.5-inch, business critical
- HDD SATA III, 7,200 rpm, 1,000 GB, 3.5-inch
- HDD SATA III, 7,200 rpm, 1,000 GB, 2.5-inch, business critical
- HDD SATA II, 5,400 rpm, 500 GB, 2.5-inch
- Drive bays 2 x 3.5-inch external bays
- 4 x 3.5-inch internal bays
- 2 x 5.25-inch external bays
- Slots 1 x PCI-Express 3.0 x4 (mech. x16)
- 1 x PCI-Express 3.0 x16
- 2 x PCI-Express 3.0 x1
- Interfaces 1 x Audio: line-in / microphone
- 1 x Audio: line-in
- 1 x Audio: line-out
- 1 x Front audio: headphone
- 1 x Front audio: microphone
- 1 x Internal speakers
- 6 x USB 2.0 total
- 2x USB 2.0; 2x USB 3.0 x USB front
- 2x USB 2.0 + 1x USB 3.0 x USB internal
- 2x USB 2.0; 4x USB 3.0 x USB rear
- 2 x DisplayPort
- 1 (optional) x Parallel (25pin with EPP and ECP)
- 1 x Serial (RS-232, 9pin, 16 byte FIFO, 16550 compatible)
- optional: via adapter card x VGA
- 1 x Ethernet (RJ-45)
- 1 (DVI-D) x DVI
- 1 (optional) x eSATA
- 2 x Mouse / Keyboard (PS/2)
- Graphics Intel® HD Graphics P530, Intel® HD Graphics 530, up to 1,782 MB
- Graphics features Support for up to three independent displays, DirectX® 12, HDCP support, OpenCL™ 2.0 (requires Intel® Core™ i3, i5 or i7 processors), OpenGL®4.4, One DisplayPort connector can be converted to DVI-D or HDMI with an optional external adapter, For multi monitoring mode, graphics card and integrated graphics run in parallel, DisplayPort interface supports Ver. 1.2 incl. Multi-Stream, DVI-D interface supports audio output for HDMI monitors
- Midrange 3D: AMD Radeon™ Pro WX 7100 , 8 GB, PCIe x16, 4 x DisplayPort
- High-end 3D: AMD FirePro™ W7100, 8 GB, PCIe x16, 4 x DisplayPort
- High-end 3D: NVIDIA® Quadro® P4000, 8 GB, PCIe x16, 4 x DisplayPort
- Midrange 3D: NVIDIA® Quadro® P2000, 5 GB, PCIe x16, 4 x DisplayPort
- Midrange 3D: AMD Radeon™ Pro WX 5100, 8 GB, 320 stream processors, PCIe x16, 4 x DisplayPort
- Midrange 3D: AMD FirePro™ W4300, 4 GB, 512 stream processors, PCIe x16, 4x miniDP, 4x miniDP/DP Adapter
- Entry 3D: NVIDIA® Quadro® P1000, 4 GB, PCIe x16, 4x miniDP
- Entry 3D: AMD Radeon™ Pro WX 3100, 4 GB, 320 stream processors, PCIe x16, 1x DisplayPort, 2x miniDP
- Entry 3D: NVIDIA® Quadro® P600, 2 GB, PCIe x16, 4x miniDP
- Professional 2D: NVIDIA® NVS™ 315 fanless, 1 GB, 48 cores, PCIe 2.0 x16, 1x LFH59 (max. 2x DP or 2x DVI-I)
- Entry 3D: AMD Radeon™ Pro WX 2100, 2 GB, 320 stream processors, PCIe x16, 1x DisplayPort, 2x miniDP
- Entry 3D: NVIDIA® Quadro® P400 , 2 GB, PCIe x16, 3x miniDP
- Entry 3D: NVIDIA® Quadro® K420, 2 GB, 192 cores, PCIe x16, 1x Dual Link DVI-I, 1x DisplayPort
- Professional 2D: NVIDIA® NVS™ 510, 2 GB, 16 cores, PCIe 2.0 x16, 4x miniDP, 4x miniDP/DP Adapter
- Professional 2D: NVIDIA® NVS™ 315, 1 GB, 48 cores, PCIe 2.0 x16, 1x LFH59 (max. 2x DP or 2x DVI-I)
- Remote Graphics: CELSIUS RemoteAccess Quad Card, PCIe x1, 4x miniDP, PCoIP
- Remote Graphics: CELSIUS RemoteAccess Dual Card, PCIe x1, 2x miniDP, PCoIP
- Others: VGA Extension Card
- Audio codec Realtek ALC671
- LAN 10/100/1,000 MBit/s Intel® I219LM
- Weight approx. 14 kg
- approx. 30.86 lbs
- Dimensions (W x D x H) 175 x 419 x 395 mm
- 6.89 x 16.5 x 15.56 inch
- Special features Best-in-class noise emission - 18 dB only, Certified for leading workstation applications, EraseDisk functionality, Halogen free mainboard, Made in Germany
- Warranty period 3 years (depending on country)
- Warranty type Bring-In / Onsite Service (for countries within region EMEIA, for all other countries depending on local regulations)
