FUJITSU Desktop ESPRIMO P557/E85+
The FUJITSU ESPRIMO P557/E85+ Desktop provides high-quality computing for your daily office tasks. It supports attractive price points and delivers the continuity needed for daily operations. Your valuable business data is protected by the latest TPM controller and the Erasedisk option. To meet your specific hardware needs it can be either individually configured or customized.
- Desktop ESPRIMO P557/E85+ VER STYLE SHEET EM PDF
- Operating system Windows 7 Professional 64-bit pre-installed (available through downgrade rights from Windows 10 Pro, with 6th generation Intel®processors)
- Windows 10 Pro. Fujitsu recommends Windows 10 Pro.
- Windows 10 Home
- Operating system notes Systems with 7th generation Intel® processor receive support from Microsoft with Windows 10 Home / Windows 10 Pro only. For more information, please see Microsoft Support Lifecycle.
- Mainboard D3500 (proprietary )
- Chipset Intel® H110
- Processor Intel® Core™ i7-7700 processor, 8 MB, 3.60 GHz, up to 4.2 GHz
- Intel® Core™ i7-6700 processor, 8 MB, 3.40 GHz, up to 4.0 GHz
- Intel® Core™ i5-7600 processor, 6 MB, 3.50 GHz, up to 4.1 GHz
- Intel® Core™ i5-7500 processor, 6 MB, 3.40 GHz, up to 3.8 GHz
- Intel® Core™ i5-6600 processor, 6 MB, 3.30 GHz, up to 3.9 GHz
- Intel® Core™ i5-6500 processor, 6 MB, 3.20 GHz, up to 3.6 GHz
- Intel® Core™ i5-7400 processor, 6 MB, 3.00 GHz, up to 3.5 GHz
- Intel® Core™ i5-6400 processor, 6 MB, 2.70 GHz, up to 3.3 GHz
- Intel® Core™ i3-7100 processor, 3 MB, 3.90 GHz
- Intel® Core™ i3-6100 processor, 3 MB, 3.70 GHz
- Intel® Pentium® processor G4400, 3 MB, 3.30 GHz
- Intel® Pentium® Gold G4560 processor, 3 MB, 3.50 GHz
- Intel® Celeron® processor G3930, 2 MB, 2.90 GHz
- Intel® Celeron® processor G3900, 2 MB, 2.80 GHz
- Supported capacity RAM (max.) 32 GB, 2 Memory slot(s) DIMM (DDR4), Dual channel support, For dual channel performance, 2 memory modules have to be ordered. Capacity per channel has to be the same.
- Serial ATA total 3
- thereof eSATA 1
- thereof SATA III Serial ATA III (6 Gbit), NCQ, AHCI
- Drives (optional) MultiCard Reader 24in1 USB 2.0 3.5", USB 2.0
- DVD-ROM
- DVD Super Multi, SATA
- DVD Super Multi ultra slim (tray), SATA
- BD Triple Writer SATA ultra slim (tray), SATA
- Hard disk drive HDD SATA II, 5,400 rpm, 500 GB, 2.5-inch
- HDD SATA III, 7,200 rpm, 1,000 GB, 3.5-inch
- HDD SATA III, 7,200 rpm, 1,000 GB, 3.5-inch, business critical
- HDD SATA III, 7,200 rpm, 2,000 GB, 3.5-inch
- HDD SATA III, 7,200 rpm, 500 GB, 3.5-inch
- PCIe-SSD, 128 GB M.2 NVMe module
- PCIe-SSD, 256 GB M.2 NVMe module
- PCIe-SSD, 512 GB M.2 NVMe module
- PCIe-SSD, 1024 GB M.2 NVMe module
- SSD SATA III, 256 GB, 2.5-inch
- SSD SATA III, 256 GB, 2.5-inch, SED
- SSD SATA III, 512 GB, 2.5-inch
- SSD SATA III, 512 GB, 2.5-inch, SED
- SSHD SATA III, 7,200 rpm, 1,000 GB, 3.5-inch
- Drive bay 1 x 3.5-inch external bay
- 1 x 3.5-inch internal bay
- 2 x 5.25-inch external bay
- Slots 1 x PCI-Express 3.0 x16
- 2 x PCI-Express x1
- Interfaces 1 x Audio: line-in
- 1 x Audio: line-out
- 1 x Front audio: headphone
- 1 x Front audio: microphone
- 4 x USB 3.1 Gen1 (USB 3.0) total
- 6 x USB 2.0 total
- 2x USB 2.0; 2x USB 3.0; optional: 1x USB 3.1 Type-C (Gen2) via add on card and front adapter bay x USB front
- 2x USB 2.0; 2x USB 3.0 x USB rear
- 2x USB 2.0 x USB internal
- optional: via adapter card x VGA
- 1 x Ethernet (RJ-45)
- 1 (DVI-D) x DVI
- 1 (optional) x eSATA
- 1 x DisplayPort
- 2 x Mouse / Keyboard (PS/2)
- Graphics Intel® HD Graphics 510, Intel® HD Graphics 530, Intel® HD Graphics 610, Intel® HD Graphics 630, up to 1,782 MB
- Audio type Realtek ALC671
- Communication 10/100/1,000 MBit/s Realtek RTL8111G
- Weight 7 kg
- 15.50 lbs
- Dimensions (W x D x H) 180 x 304 x 375 mm
- 7.09 x 11.97 x 14.76 inch
- Power efficiency note power supply efficiency (at 230V; 10% / 20% / 50% / 100% load) : 75% / 83% / 85% / 84%
- Special features Made in Germany, EraseDisk functionality, TPM
- Warranty period 1 year (for countries in EMEIA)
- Warranty type Bring-In / Onsite Service (for countries within region EMEIA, for all other countries depending on local regulations)
